Lumimax Conductive Polymer Aluminum Electrolytic Capacitors





	Lumimax Part NumberCapacitanceESRRated VoltageLeakage CurrentRated Ripple CurrentOperating Temperature






	PDFLPCX025M470K47μF80mΩ25V352.5μA1500mA-55°C ~ 105°C




	PDFLPCS002Y331S330μF9mΩ2V66μA7700mA-55°C ~ 105°C




	PDFLPCS2P5Y331S330μF9mΩ2.5V82.5μA7700mA-55°C ~ 105°C




	PDFLPCT002M471U470μF3mΩ2V94μA10200mA-55°C ~ 105°C




	PDFLPCT002M471L470μF4.5mΩ2V94μA8500mA-55°C ~ 105°C




	PDFLPCT002M471E470μF6mΩ2V94μA7500mA-55°C ~ 105°C




	PDFLPCT002M471S470μF9mΩ2V94μA6300mA-55°C ~ 105°C




	PDFLPCT2P5M471U470μF3mΩ2.5V117.5μA10200mA-55°C ~ 105°C




	PDFLPCT2P5M471L470μF4.5mΩ2.5V117.5μA8500mA-55°C ~ 105°C




	PDFLPCT2P5M471E470μF6mΩ2.5V117.5μA7500mA-55°C ~ 105°C




	PDFLPCT2P5M471S470μF9mΩ2.5V117.5μA6300mA-55°C ~ 105°C




	PDFLPCX002M471U470μF3mΩ2V94μA10200mA-55°C ~ 105°C




	PDFLPCX002M471L470μF4.5mΩ2V94μA8500mA-55°C ~ 105°C




	PDFLPCX002M471E470μF6mΩ2V94μA7500mA-55°C ~ 105°C




	PDFLPCX002M471S470μF9mΩ2V94μA6300mA-55°C ~ 105°C




	PDFLPCX2P5M471U470μF3mΩ2.5V117.5μA10200mA-55°C ~ 105°C




	PDFLPCX2P5M471L470μF4.5mΩ2.5V117.5μA8500mA-55°C ~ 105°C




	PDFLPCX2P5M471E470μF6mΩ2.5V117.5μA7500mA-55°C ~ 105°C




	PDFLPCX2P5M471S470μF9mΩ2.5V117.5μA6300mA-55°C ~ 105°C




	PDFLPCX002M561U560μF3mΩ2V112μA10200mA-55°C ~ 105°C




	PDFLPCX002M561L560μF4.5mΩ2V112μA8500mA-55°C ~ 105°C




	PDFLPCX002M561E560μF6mΩ2V112μA7500mA-55°C ~ 105°C




	PDFLPCX2P5M561U560μF3mΩ2.5V140μA10200mA-55°C ~ 105°C




	PDFLPCX2P5M561L560μF4.5mΩ2.5V140μA8500mA-55°C ~ 105°C




	PDFLPCX2P5M561E560μF6mΩ2.5V140μA7500mA-55°C ~ 105°C




	PDFLPCX002K821U820μF3mΩ2V164μA10200mA-55°C ~ 105°C
