P6KE series


Part Number
PPK (W)
Package
VRWM (V)
IPP (A)
VC Clamp (V)
Configuration
TJ Max. (°C)





P6KE6.8A
600
DO-15
5.8
57.14
10.5
Unidirectional
175



P6KE7.5A
600
DO-15
6.4
53.1
11.3
Unidirectional
175



P6KE8.2A
600
DO-15
7
49.59
12.1
Unidirectional
175



P6KE9.1A
600
DO-15
7.8
44.78
13.4
Unidirectional
175



P6KE10A
600
DO-15
8.6
41.38
14.5
Unidirectional
175



P6KE11A
600
DO-15
9.4
38.46
15.6
Unidirectional
175



P6KE12A
600
DO-15
10.2
35.93
16.7
Unidirectional
175



P6KE13A
600
DO-15
11.1
32.97
18.2
Unidirectional
175



P6KE15A
600
DO-15
12.8
28.3
21.2
Unidirectional
175



P6KE16A
600
DO-15
13.6
26.67
22.5
Unidirectional
175



P6KE18A
600
DO-15
15.3
23.81
25.2
Unidirectional
175



P6KE20A
600
DO-15
17.1
21.66
27.7
Unidirectional
175



P6KE22A
600
DO-15
18.8
19.61
30.6
Unidirectional
175



P6KE24A
600
DO-15
20.5
18.07
33.2
Unidirectional
175



P6KE27A
600
DO-15
23.1
16
37.5
Unidirectional
175



P6KE30A
600
DO-15
25.6
14.49
41.4
Unidirectional
175



P6KE33A
600
DO-15
28.2
13.13
45.7
Unidirectional
175



P6KE36A
600
DO-15
30.8
12.02
49.9
Unidirectional
175



P6KE39A
600
DO-15
33.3
11.13
53.9
Unidirectional
175



P6KE43A
600
DO-15
36.8
10.12
59.3
Unidirectional
175



P6KE47A
600
DO-15
40.2
9.26
64.8
Unidirectional
175



P6KE51A
600
DO-15
43.6
8.56
70.1
Unidirectional
175



P6KE56A
600
DO-15
47.8
7.79
77
Unidirectional
175



P6KE62A
600
DO-15
53
7.06
85
Unidirectional
175



P6KE68A
600
DO-15
58.1
6.52
92
Unidirectional
175



P6KE75A
600
DO-15
64.1
5.83
103
Unidirectional
175



P6KE82A
600
DO-15
70.1
5.31
113
Unidirectional
175



P6KE91A
600
DO-15
77.8
4.8
125
Unidirectional
175



P6KE100A
600
DO-15
85.5
4.38
137
Unidirectional
175



P6KE110A
600
DO-15
94
3.95
152
Unidirectional
175



P6KE120A
600
DO-15
102
3.64
165
Unidirectional
175



P6KE130A
600
DO-15
111
3.35
179
Unidirectional
175



P6KE150A
600
DO-15
128
2.9
207
Unidirectional
175



P6KE160A
600
DO-15
136
2.74
219
Unidirectional
175



P6KE170A
600
DO-15
145
2.56
234
Unidirectional
175



P6KE180A
600
DO-15
154
2.44
246
Unidirectional
175



P6KE200A
600
DO-15
171
2.19
274
Unidirectional
175



P6KE220A
600
DO-15
185
1.83
328
Unidirectional
175



P6KE250A
600
DO-15
214
1.74
344
Unidirectional
175



P6KE300A
600
DO-15
256
1.45
414
Unidirectional
175



P6KE350A
600
DO-15
299.3
1.24
482
Unidirectional
175



P6KE380A
600
DO-15
324.9
1.14
524.4
Unidirectional
175



P6KE400A
600
DO-15
342
1.09
548
Unidirectional
175



P6KE440A
600
DO-15
376.2
0.99
607.2
Unidirectional
175



P6KE500A
600
DO-15
427.5
0.87
690
Unidirectional
175



P6KE520A
600
DO-15
444.6
0.84
717.6
Unidirectional
175



P6KE550A
600
DO-15
470.3
0.79
759
Unidirectional
175



P6KE600A
600
DO-15
513
0.72
828
Unidirectional
175



P6KE6.8CA
600
DO-15
5.8
57.14
10.5
Bidirectional
175



P6KE7.5CA
600
DO-15
6.4
53.1
11.3
Bidirectional
175



P6KE8.2CA
600
DO-15
7
49.59
12.1
Bidirectional
175



P6KE9.1CA
600
DO-15
7.8
44.78
13.4
Bidirectional
175



P6KE10CA
600
DO-15
8.6
41.38
14.5
Bidirectional
175



P6KE11CA
600
DO-15
9.4
38.46
15.6
Bidirectional
175



P6KE12CA
600
DO-15
10.2
35.93
16.7
Bidirectional
175



P6KE13CA
600
DO-15
11.1
32.97
18.2
Bidirectional
175



P6KE15CA
600
DO-15
12.8
28.3
21.2
Bidirectional
175



P6KE16CA
600
DO-15
13.6
26.67
22.5
Bidirectional
175



P6KE18CA
600
DO-15
15.3
23.81
25.2
Bidirectional
175



P6KE20CA
600
DO-15
17.1
21.66
27.7
Bidirectional
175



P6KE22CA
600
DO-15
18.8
19.61
30.6
Bidirectional
175



P6KE24CA
600
DO-15
20.5
18.07
33.2
Bidirectional
175



P6KE27CA
600
DO-15
23.1
16
37.5
Bidirectional
175



P6KE30CA
600
DO-15
25.6
14.49
41.4
Bidirectional
175



P6KE33CA
600
DO-15
28.2
13.13
45.7
Bidirectional
175



P6KE36CA
600
DO-15
30.8
12.02
49.9
Bidirectional
175



P6KE39CA
600
DO-15
33.3
11.13
53.9
Bidirectional
175



P6KE43CA
600
DO-15
36.8
10.12
59.3
Bidirectional
175



P6KE47CA
600
DO-15
40.2
9.26
64.8
Bidirectional
175



P6KE51CA
600
DO-15
43.6
8.56
70.1
Bidirectional
175



P6KE56CA
600
DO-15
47.8
7.79
77
Bidirectional
175



P6KE62CA
600
DO-15
53
7.06
85
Bidirectional
175



P6KE68CA
600
DO-15
58.1
6.52
92
Bidirectional
175



P6KE75CA
600
DO-15
64.1
5.83
103
Bidirectional
175



P6KE82CA
600
DO-15
70.1
5.31
113
Bidirectional
175



P6KE91CA
600
DO-15
77.8
4.8
125
Bidirectional
175



P6KE100CA
600
DO-15
85.5
4.38
137
Bidirectional
175



P6KE110CA
600
DO-15
94
3.95
152
Bidirectional
175



P6KE120CA
600
DO-15
102
3.64
165
Bidirectional
175



P6KE130CA
600
DO-15
111
3.35
179
Bidirectional
175



P6KE150CA
600
DO-15
128
2.9
207
Bidirectional
175



P6KE160CA
600
DO-15
136
2.74
219
Bidirectional
175



P6KE170CA
600
DO-15
145
2.56
234
Bidirectional
175



P6KE180CA
600
DO-15
154
2.44
246
Bidirectional
175



P6KE200CA
600
DO-15
171
2.19
274
Bidirectional
175



P6KE220CA
600
DO-15
185
1.83
328
Bidirectional
175



P6KE250CA
600
DO-15
214
1.74
344
Bidirectional
175



P6KE300CA
600
DO-15
256
1.45
414
Bidirectional
175



P6KE350CA
600
DO-15
299.3
1.24
482
Bidirectional
175



P6KE380CA
600
DO-15
324.9
1.14
524.4
Bidirectional
175



P6KE400CA
600
DO-15
342
1.09
548
Bidirectional
175



P6KE440CA
600
DO-15
376.2
0.99
607.2
Bidirectional
175



P6KE500CA
600
DO-15
427.5
0.87
690
Bidirectional
175



P6KE520CA
600
DO-15
444.6
0.84
717.6
Bidirectional
175



P6KE550CA
600
DO-15
470.3
0.79
759
Bidirectional
175



P6KE600CA
600
DO-15
513
0.72
828
Bidirectional
175
